Starting from $31,995 + gst
The Pioneer 1000 takes everything we have learnt from our ATVs and side-by-sides and added to them.
From the 450kg hauling to the 900kg towing capacity, it is designed to take what you need to where you need it.
Fully-independent front and rear suspension with some of the longest travel of any multi-purpose side-by-side. And open or locked front and rear differentials that prevent you from unnecessarily tearing up delicate surfaces.
Let’s remember: this is a Honda, a name that’s long stood for quality and reliability.
So you get class-leading power, performance and features, purpose-built by the best in the business.
Features over base model include:
Black aluminum Wheels
Under seat / Under dash storage
Accessory outlet in cargo deck
Winch (4500lb/2000kg)
i-4WD
Standard dual bed lights
Cabin lighting
Self-leveling rear suspension
Full front bumper
Base Features include:
999cc Engine
Automatic DCT Transmission
Electric Power Steering
Independent Front and Rear Suspension
1100 kg Towing Capacity
High/Low Subtransmission
450kg Capacity Tilt Bed
Four-Wheel Disc Brakes
Upgrades from previous model include:
Increased power in the middle and upper rpm ranges
Transmission Updates
Power steering – improved lighter and reduces harsh kickback
In-door drink-bottle holders
New Door Nets – simplified mounting & improved visibility
Pre-wired Accessory Connector
Dash Switch Panel
New improved Dash
14-inch wheels
More Ground clearance
Longer suspension travel
Styling – new grill and fascia, along with updated graphics
7.95% HONDA RIDER FINANCE DEAL ON NOW – ENQUIRE FOR MORE DETAILS.
SPECIFICATIONS
![Pioneer SXS1000-M3F (Forest) Image](https://www.southlandhonda.co.nz/nov/wp-content/uploads/2024/04/22-Honda-Pioneer-1000-Forest_LF-600x460.jpg)
ENGINE
Engine Type
999cc liquid-cooled OHC Unicam parallel-twin four-stroke, 4 valves/cylinder
CC Rating
999cc
Bore and Stroke
92.0 x 75.15
Ignition
Full transistorized ignition
Compression Ratio
10:1
TRANSMISSION
Starter
Electric
Gearbox
Automatic DCT w/ 6 speeds + reverse and high/low; drive modes include 2WD, 4WD, Turf, 1-4WD
WHEELS, SUSPENSION & BRAKES
Suspension Front
Independent double-wishbone; 267mm travel
Suspension Rear
Independent double-wishbone; 254mm travel
Brakes Front
Hydraulic w/ (2) 210mm discs
Brakes Rear
Hydraulic w/ (2) 210mm discs
Tyres Front
27 x 9 x 14
Tyres Rear
27 x 11 x 14
DIMENSIONS & WEIGHT
Wheelbase
2037mm
Ground Clearance
328mm
Kerb Weight
760kg
Fuel Capacity
29.9 litres (including 6.4 litres reserve)
Dimensions
2967mm(L) x 1598mm(W) x 1933mm(H)
Features
![6-Speed DCT Transmission Image](https://www.southlandhonda.co.nz/nov/wp-content/uploads/2022/05/Screenshot-2022-05-11-104452-345x345.jpg)
6-Speed DCT Transmission
An industry first 6-speed Dual Clutch Transmission. Choose between manual mode or fully automatic as well as utilizing the built-in Sports Mode.
![i-4WD Image](https://www.southlandhonda.co.nz/nov/wp-content/uploads/2024/04/22-Honda-Pioneer-1000_Red-dash-scaled-e1713559964702-345x345.jpg)
i-4WD
Honda’s exclusive i-4WD system (“intelligent four-wheel drive”), is standard equipment on Pioneer 1000 Trail and Forest versions. This ingenious system is a combination of brake traction control and torque-biasing, limited-slip front differential, managing the four-wheel-drive and differential-locking functions into a single selection mode, resulting in unparalleled benefits.
![Hidden attributes Image](https://www.southlandhonda.co.nz/nov/wp-content/uploads/2022/05/Screenshot-2022-05-11-104824-345x345.jpg)
Hidden attributes
Some of the most impressive Pioneer 1000 features are those you’ll never see. In addition to the suspension and ground clearance, we rubber-mounted the engine and exhaust system to insulate the cabin against excessive vibration. So while you may not see this feature, it’s one you will definitely notice.
